Honda GCV160 User Manual

PARTS CATALOGUE NEWS
BOOKNo.:13ZM00E8
Reqd.QTY
Block
No.
Ref.
No.
Part No. Description
GCV GCV GCV GCV GCV GCV GCV
160 160 160 160 160 160 160
A A0 E LE LA LA0
Base Part No. Parts catalogue code
E-16 2 18321-Z0L-810 PROTECTOR, MUFFLER............ - - 1 - - - - 18321-Z0L-J01 SBTE
E-22 1 ARM, GOVERNOR................. - - 0 - - - - 16551-ZM0-010 SBTE
2 ROD, GOVERNOR................. - - 0 - - - - 16555-Z0L-801 SBTE
3 SPRING, GOVERNOR.............. - - 0 - - - - 16561-Z0L-000 SBTE
4 SPRING, THROTTLE RETURN....... - - 0 - - - - 16562-ZM0-000 SBTE
10 BOLT, GOVERNOR ARM............ - - 0 - - - - 90015-ZE5-010 SBTE
13 NUT, FLANGE, 6MM.............. - - 0 - - - - 94050-06000 SBTE
E-22-2 1 16551-ZM0-010 ARM, GOVERNOR................. - - 1 - - - - SBTE
2 16555-Z0L-801 ROD, GOVERNOR................. - - 1 - - - - SBTE
3 16561-Z0L-000 SPRING, GOVERNOR.............. - - 1 - - - - SBTE
4 16562-ZM0-000 SPRING, THROTTLE RETURN....... - - 1 - - - - SBTE
12 90015-ZE5-010 BOLT, GOVERNOR ARM............ - - 1 - - - - SBTE
15 94050-06000 NUT, FLANGE, 6MM.............. - - 1 - - - - SBTE
18 16221-Z0L-900 SPACER, CARBURETOR............ - - 1 - - - - SBTE
E-28 30 MARK, EMBLEM(GCV160).......... - - 0 - - - - 87101-Z8B-000 SBTE
34 87519-Z0J-000 MARK, OPERATOR CAUTION........ - - 1 - - - - SBTE
37 87114-ZH7-850 LABEL, WARNING................ - - 1 - - - - 87114-ZH7-821 SBTE
NOTE A:PART NO.CHANGE D:NEWLY PROVIDED E:PART NO.DELETION K:REQUIRED NO.CORRECTION L:APPLICATION SERIAL NO.CORRECTION
T:APPLICATION CORRECTION Z:REMARKS CHANGE
4/4

Honda GCV160 Specifications

General

Compression Ratio	8.5:1
PTO Shaft Rotation	Counterclockwise (from PTO shaft side)
Cooling System	Forced air
Ignition System	Transistorized magneto
Starting System	Recoil Starter
Engine Type	Air-cooled 4-stroke
Displacement	160 cm3 (9.8 cu in)
Bore x Stroke	68 mm x 45 mm
Net Power Output	3.3 kW (4.4 HP) @ 3, 600 rpm
Oil Capacity	0.55 L (0.58 US qt)
Dimensions	335 mm
