Honda GCV160 User Manual

36
1
2009.01.10 E
Major service items without using spare parts
(1) Removal/Installation, (2) Adjustment,
(3) Inspection/Measurement, (4) Overhaul, (5) Other work
(2) Adjustment
(3) Inspection, Measurement, Cleaning
(4) Overhaul
Work condition: The required Measurements, inspections,
adjustments, and cleaning/washing of each part are performed,
including the main body removal/installation work and the
replacement of defective parts.
LON DESCRIPTION FRT
E
1113A1
VALVE CLEARANCE-ADJUSTMENT
NOTE: For 1 product
0.3
1163A0
CONTROL, THROTTLE/GOVERNOR-
ADJUSTMENT
0.2
3113A2 CARBURETOR IDLE-ADJUSTMENT 0.2
LON DESCRIPTION FRT
E
1105A0 ENGINE OIL-INSPECTION 0.1
3120A0
AIR CLEANER-CLEANING
INCLUDES: Air cleaner-inspection
0.1
3130A0
SPARK ARRESTER-CLEANING
INCLUDES: Spark arrester-inspection
0.2
6140A0
SPARK PLUG-ADJUSTMENT/CLEANING
INCLUDES: Spark plug check
NOTE: For 1 product
0.2
LON DESCRIPTION FRT
E 3112A0
CARBURETOR-OVERHAUL
INCLUDES: All necessary adjustment
0.6
E: Engine, T: Transmission, D: Drive system,
B: Body and related parts
(5) Other work
LON DESCRIPTION FRT
E 1101E1
ENGINE OIL-CHANGE
INCLUDES: Engine oil-inspection
0.1
D 4

Honda GCV160 Specifications

General

Compression Ratio	8.5:1
PTO Shaft Rotation	Counterclockwise (from PTO shaft side)
Cooling System	Forced air
Ignition System	Transistorized magneto
Starting System	Recoil Starter
Engine Type	Air-cooled 4-stroke
Displacement	160 cm3 (9.8 cu in)
Bore x Stroke	68 mm x 45 mm
Net Power Output	3.3 kW (4.4 HP) @ 3, 600 rpm
Oil Capacity	0.55 L (0.58 US qt)
Dimensions	335 mm
