Honda GCV160 User Manual

2009.01.10 E
E-3
41
CYLINDER BARREL
2
8 98079-56846 PLUG, SPARK (BPR6ES)(NGK) ••• 1 - - - - 1 -
- 1 1 1 1 - - -------- -------- A1AE,A1AF,A1AS,A1C,A1E,BHH,C1E,C1E1,C2E,C2E1,N1L
- 1 - 1 1 - 1 -------- -------- N1AF,N5AF,N5MF,N5R,N7A1,N7S1
- 1 - 1 1 - - -------- -------- A1A,A1M,A2A,A2C,A3A,A3E,A7E1,A7H1,BHH1,EHHB,E1A2
E1A4,E1G7,E2G7,E5A4,NBL1,N1C,N1U,N2U,N3U,N3V,N5A
N5C,RTL1,R1A,R3A,R3A1,STA1,STL1,S1A,S1A1,S1M,S2G7
S3A,S3A2,S3H,S3H2
- 1 - - - - 1 -------- -------- A1E7,A1E8,A1W7,A2E7,A2E8,A2E9,A2G7,N1A,N1E1,N1E7
N1R,N1W7,N1W8,N1W9,N2E7,N2E8,N2E9
- 1 - - - - - -------- -------- A2R
- - 1 - - - - -------- -------- C3E,C3E1,C4E,C4E1
- - - 1 1 - - -------- 2218977 A1E7,A1E8,A1G7,A1G9,A1P,A1W7,A2A9,A2E7,A2E8,A2E9
A2G4,A2G7,A2G9,A2R,A3E7,A3E9,A3G9,A3T9,A3W7,A3W8
A4A9,A4G4,A4G7,A4G9,N1D,N1E1,N1E2,N1E7,N1J1,N1R
N1T8,N1T9,N1W7,N1W8,N1W9,N2E7,N2E8,N2E9,N3T8,N3T9
N3W8,N3W9,S1E1,S2E,S2E1,S2E2,S2E3,S3E9,S3G9,S4E4
S4E9,S4G4,S4G9
98079-55846 PLUG, SPARK (BPR5ES)(NGK) ••• - 1 1 - - - - -------- -------- A1AW,C3E,C3E1,C4E,C4E1
- - 1 - - - 1 -------- -------- A1A,A1AF,A1E7,A1M,A2E7,A2R,BHH,BHH1,C1E,C1E1,C2E
C2E1,E1A2,E2G7,N1R,N1U,N2U,N3U,N3V,R3A,S1A,S1M
S2G7,S3A,S3H,S3H2
- - - 1 1 - - 2218978 -------- A1E7,A1E8,A1G7,A1G9,A1P,A1W7,A2A9,A2E7,A2E8,A2E9
A2G4,A2G7,A2G9,A2R,A3E7,A3E9,A3G9,A3T9,A3W7,A3W8
A4A9,A4G4,A4G7,A4G9,N1D,N1E1,N1E2,N1E7,N1J1,N1R
N1T8,N1T9,N1W7,N1W8,N1W9,N2E7,N2E8,N2E9,N3T8,N3T9
N3W8,N3W9,S1E1,S2E,S2E1,S2E2,S2E3,S3E9,S3G9,S4E4
S4E9,S4G4,S4G9
9 12000-ZL8-415 BARREL ASSY., CYLINDER •••••• 1 - - - - - - -------- -------- A1E7,A1E8,A1G7,A1W7,A2E7,A2E8,A2E9,A2G7,A7E1,N1E7
N1J1,N1R,N1W7,N1W8,N1W9,N2E7,N2E8,N2E9,N3U,N7A1
Ref.
No.
Part No. Description
Reqd. QTY
Parts catalogue code
GCV GCV GCV GCV GCV GCV GCV
160 160 160 160 160 160 160
A A0 E LE LA LA0
Serial No.
+13 .INCLUDES: Valve clearance
adjustment
1111P3A .Replace intake and exhaust
all add ••••••••••••••••••••• 0.1
1111P4 SPRING, VALVE :EXHAUST ••••••• 1.2
.INCLUDES: Valve clearance
adjustment
1111P4A .Replace intake and exhaust
all add ••••••••••••••••••••• 0.1
Ref.
No.
L.O.N.
(Relative ref. Number)
Description
F.R.T.
E 2

Honda GCV160 Specifications

General

Compression Ratio	8.5:1
PTO Shaft Rotation	Counterclockwise (from PTO shaft side)
Cooling System	Forced air
Ignition System	Transistorized magneto
Starting System	Recoil Starter
Engine Type	Air-cooled 4-stroke
Displacement	160 cm3 (9.8 cu in)
Bore x Stroke	68 mm x 45 mm
Net Power Output	3.3 kW (4.4 HP) @ 3, 600 rpm
Oil Capacity	0.55 L (0.58 US qt)
Dimensions	335 mm
