Honda GX240 User Manual

8
CONTROLS & FEATURES
CONTROLS
Fuel Valve Lever
OONN
OOFFFF
FUEL VALVE LEVER
The fuel valve opens and closes the passage between the fuel tank
and the carburetor.
The fuel valve lever must be in the ON position for the engine to run.
When the engine is not in use, leave the fuel valve lever in the OFF
position to prevent carburetor flooding and to reduce the possibility of
fuel leakage.
03/08/21 20:07:18 31ZH9613_009

Honda GX240 Specifications

General

Compression Ratio	8.2:1
PTO Shaft Rotation	Counterclockwise (from PTO shaft side)
Ignition System	Transistorized magneto ignition
Fuel System	Carburetor
Lubrication System	Forced splash
Displacement	242 cm³
Net Power Output	3, 600 rpm
Net Torque	2, 500 rpm
Fuel Tank Capacity	5.3 liters
Oil Capacity	1.1 liters
Starting System	Recoil starter
Dry Weight	25 kg (55 lbs)
Bore x Stroke	73.0 x 58.0 mm (2.9 x 2.3 in)
