Honda GX240 User Manual

35
SERVICING YOUR ENGINE
CLIP
CLIP
AIR CLEANER COVER
AIR CLEANER ELEMENT
ELEMENT
Low Profile Types
Unsnap the air cleaner cover clips,
remove the air cleaner cover, and
remove the element.
Wash the air filter in a solution of
household detergent and warm
water, then rinse thoroughly, or
wash in nonflammable or high
flashpoint solvent. Allow the air
filter to dry thoroughly.
Soak the air filter in clean engine
oil and squeeze out the excess oil.
The engine will smoke during
initial startup if too much oil is left
in the air filter.
Reinstall the air cleaner element
and the cover.
1.
2.
4.
3.
03/08/21 20:11:45 31ZH9613_036

Honda GX240 Specifications

General

Compression Ratio	8.2:1
PTO Shaft Rotation	Counterclockwise (from PTO shaft side)
Ignition System	Transistorized magneto ignition
Fuel System	Carburetor
Lubrication System	Forced splash
Displacement	242 cm³
Net Power Output	3, 600 rpm
Net Torque	2, 500 rpm
Fuel Tank Capacity	5.3 liters
Oil Capacity	1.1 liters
Starting System	Recoil starter
Dry Weight	25 kg (55 lbs)
Bore x Stroke	73.0 x 58.0 mm (2.9 x 2.3 in)
