7
COMPONENT & CONTROL LOCATIONS
CONTROLS & FEATURES
TUBE CLIP
BREATHER TUBE
MUFFLER
AIR CLEANER
THROTTLE LEVER
RECOIL STARTER
CHOKE LEVER
SPARK PLUG
FUEL FILLER CAP
FUEL TANK
OIL DRAIN PLUG
OIL FILLER CAP
FUEL VALVE LEVER
Internal vent carburetor
type (with TUBE CLIP)
STARTER GRIP
ELECTRIC STARTER
(applicable types only)
ENGINE SWITCH
(applicable
types only)
CIRCUIT BREAKER
(applicable types only)
[]
