Honda GX240 User Manual

36
SERVICING YOUR ENGINE
SEDIMENT CUP CLEANING
O-RING
SEDIMENT CUP
Move the fuel valve to the OFF position, then remove the fuel
sediment cup and O-ring.
Gasoline is highly flammable and
explosive.
You can be burned or seriously
injured when handling fuel.
Keep heat, sparks and flame away.
Handle fuel only outdoors.
Wipe up spills immediately.
Wash the sediment cup and O-ring in nonflammable solvent, and
dry them thoroughly.
Place the O-ring in the fuel valve, and install the sediment cup.
Tighten the sediment cup securely.
Move the fuel valve to the ON position, and check for leaks.
Replace the O-ring if there is any leakage.
1.
2.
4.
3.
03/08/21 20:11:53 31ZH9613_037

Honda GX240 Specifications

General

Compression Ratio	8.2:1
PTO Shaft Rotation	Counterclockwise (from PTO shaft side)
Ignition System	Transistorized magneto ignition
Fuel System	Carburetor
Lubrication System	Forced splash
Displacement	242 cm³
Net Power Output	3, 600 rpm
Net Torque	2, 500 rpm
Fuel Tank Capacity	5.3 liters
Oil Capacity	1.1 liters
Starting System	Recoil starter
Dry Weight	25 kg (55 lbs)
Bore x Stroke	73.0 x 58.0 mm (2.9 x 2.3 in)
