Honda HRN216PKA User Manual

9-8
IGNITION COIL/FLYWHEEL HRN216
2. FLYWHEEL
DISASSEMBLY/REASSEMBLY
1. Remove the fan cover (P. 7 -3 ).
2. Remove the ignition coil (P. 9 - 2
).
3. Remove the electric starter (VLA type only) (P. 9 -1 2
).
PKA/VKA/VLA types: 55 N•m (41 ft-lb)
VYA type: 75 N•m (55 ft-lb)
FLYWHEEL NUT (14 mm)
INSTALLATION:
When installing the flywheel, check
to be sure that the woodruff key
remains in its slot in the crankshaft.
FLYWHEEL
WOODRUFF KEY
