10-18
CAMSHAFT/CRANKSHAFT/ PISTON/CYLINDER
HRN216
7. OIL FILLER CAP / EXTENSION REMOV
AL/INST
ALLA
TION
O-RING
OIL FILLER CAP/DIPSTICK
OIL FILLER EXTENSION
OIL FILL
ER P
ACKING
6 x 14 mm SPECIAL BOL
T (2)
12 N•m (9 ft-lb)
INSTALLATION:
Be sure that no
dust or
foreign material e
nters
when installi
ng the O-ring.
Be careful not to p
inch the
O-ring.
140
