Honda Interceptor 2014 User Manual

Removing & Installing Body Components u Single Seat Cowl
67
continued
Maintenance
Single Seat Cowl
❙
Installation of Single Seat Cowl
1. Remove the rear seat. 2 P. 65
2. Remove the bolts.
3. Remove the grab rail mounting bolts/
washers.
4. Remove the grab rails.
5. Install the grab rail covers.
6. Install and tighten the grab rail mounting
bolts/washers.
7. Install and tighten the bolts securely.
Grab
rail
Bolt
Bolt
Grab
rail
Mounting
bolts /washers
Torque: 20 lbf·ft (27 N·m, 2.8 kgf·m).
Mounting
bolts /washers
Grab
rail
cover
Grab
rail
cover
Bolt
Bolt

Honda Interceptor 2014 Specifications

General

Displacement	782cc
Bore x Stroke	72mm x 48mm
Compression Ratio	11.8:1
Ignition	Computer-controlled digital transistorized with electronic advance
Transmission	6-speed
Final Drive	O-ring-sealed chain
Front Tire	120/70ZR-17 radial
Rear Tire	180/55ZR-17 radial
Rake (Caster Angle)	25.5 degrees
Engine Type	Liquid-cooled 90-degree V-4
Fuel System	PGM-FI with automatic enrichment circuit
Rear Suspension	Pro-Link HMAS single shock with spring preload adjustability
Front Brake	Dual 310mm discs
Rear Brake	Single 256mm disc
Curb Weight	529 pounds
Valve Train	DOHC; 4 valves per cylinder
Fuel Delivery	PGM-FI
Wheelbase (Alternative)	55.5 inches
Front Suspension (Alternative)	41mm inverted HMAS cartridge fork with spring preload, rebound and compression damping adjustability; 4.7 inches travel
Rear Suspension (Alternative)	Pro-Link single shock
Trail	98mm (3.9 inches)
