Honda Interceptor 2014 User Manual

Other Adjustments u Adjusting the Rear Suspension
91
continued
Maintenance
Adjusting the Rear Suspension
❙
Spring Preload
You can adjust the spring preload by the
adjuster knob to suit the load or the road
surface. Turn clockwise to increase spring
preload (hard), or turn counterclockwise to
decrease spring preload (soft). The standard
position is 7 clicks from the minimum setting.
You can adjust the spring preload by the
adjuster to suit the load or the road surface.
Use the pin spanner and extension bar to
turn the adjuster. Position 1 is for a decrease
spring preload (soft), or turn the position 3 to
7 increase spring preload (hard). The
standard position is 2.
Attempting to adjust directly from 1 to 7 or 7
to 1 may damage the shock absorber.
INTERCEPTOR DELUXE
Adjuster knob
INTERCEPTOR
Adjuster
1
2
3
4
5
6
7

Honda Interceptor 2014 Specifications

General

Displacement	782cc
Bore x Stroke	72mm x 48mm
Compression Ratio	11.8:1
Ignition	Computer-controlled digital transistorized with electronic advance
Transmission	6-speed
Final Drive	O-ring-sealed chain
Front Tire	120/70ZR-17 radial
Rear Tire	180/55ZR-17 radial
Rake (Caster Angle)	25.5 degrees
Engine Type	Liquid-cooled 90-degree V-4
Fuel System	PGM-FI with automatic enrichment circuit
Rear Suspension	Pro-Link HMAS single shock with spring preload adjustability
Front Brake	Dual 310mm discs
Rear Brake	Single 256mm disc
Curb Weight	529 pounds
Valve Train	DOHC; 4 valves per cylinder
Fuel Delivery	PGM-FI
Wheelbase (Alternative)	55.5 inches
Front Suspension (Alternative)	41mm inverted HMAS cartridge fork with spring preload, rebound and compression damping adjustability; 4.7 inches travel
Rear Suspension (Alternative)	Pro-Link single shock
Trail	98mm (3.9 inches)
