Other Adjustments u Changing the Front Seat Height
94
Maintenance
Changing the Front Seat Height
The front seat can be changed to one of two
positions according to your preference.
To change the seat height, use the proper
hex wrench.
In the interest of safety, we recommend that
you have your dealer perform the
adjustment.
1. Remove the front seat. 2 P. 66
2. Remove the socket bolts A and seat adjust
plates.
3. Move the adjust plates and install the
socket bolts A in the mounting holes for
your preferred seat position (high or low),
and then tighten them.
4. If you change the front seat height from
high position to low position, remove the
socket bolts B/set collars from the seat rail.
(The socket bolts B/set collars are not
required for the low position.)
u Make sure to install the socket bolts B/
set collars when the seat height is
returned to the high position. Tighten
the socket bolts B if reinstalling.
Torque: 16 lbf·ft (22 N·m, 2.2 kgf·m).
Torque: 9 lbf·ft (12 N·m, 1.2 kgf·m).
Adjust plates
Socket bolts B/set collars
Socket bolts A
High
position:
Low
position:

Honda Interceptor 2014 Specifications

General

Displacement	782cc
Bore x Stroke	72mm x 48mm
Compression Ratio	11.8:1
Ignition	Computer-controlled digital transistorized with electronic advance
Transmission	6-speed
Final Drive	O-ring-sealed chain
Front Tire	120/70ZR-17 radial
Rear Tire	180/55ZR-17 radial
Rake (Caster Angle)	25.5 degrees
Engine Type	Liquid-cooled 90-degree V-4
Fuel System	PGM-FI with automatic enrichment circuit
Rear Suspension	Pro-Link HMAS single shock with spring preload adjustability
Front Brake	Dual 310mm discs
Rear Brake	Single 256mm disc
Curb Weight	529 pounds
Valve Train	DOHC; 4 valves per cylinder
Fuel Delivery	PGM-FI
Wheelbase (Alternative)	55.5 inches
Front Suspension (Alternative)	41mm inverted HMAS cartridge fork with spring preload, rebound and compression damping adjustability; 4.7 inches travel
Rear Suspension (Alternative)	Pro-Link single shock
Trail	98mm (3.9 inches)
