Honda Interceptor 2014 User Manual

Removing & Installing Body Components u Battery Cover
71
Maintenance
Battery Cover
The battery cover must be removed to
remove the battery, to service the main and
fuse box fuses.
❙
Removal
1. Remove the front seat. 2 P. 66
2. Remove the clips.
3. Remove the battery cover.
❙
Installation
Install the parts in the reverse order of
removal.
Battery cover
Clips

Honda Interceptor 2014 Specifications

General

Displacement	782cc
Bore x Stroke	72mm x 48mm
Compression Ratio	11.8:1
Ignition	Computer-controlled digital transistorized with electronic advance
Transmission	6-speed
Final Drive	O-ring-sealed chain
Front Tire	120/70ZR-17 radial
Rear Tire	180/55ZR-17 radial
Rake (Caster Angle)	25.5 degrees
Engine Type	Liquid-cooled 90-degree V-4
Fuel System	PGM-FI with automatic enrichment circuit
Rear Suspension	Pro-Link HMAS single shock with spring preload adjustability
Front Brake	Dual 310mm discs
Rear Brake	Single 256mm disc
Curb Weight	529 pounds
Valve Train	DOHC; 4 valves per cylinder
Fuel Delivery	PGM-FI
Wheelbase (Alternative)	55.5 inches
Front Suspension (Alternative)	41mm inverted HMAS cartridge fork with spring preload, rebound and compression damping adjustability; 4.7 inches travel
Rear Suspension (Alternative)	Pro-Link single shock
Trail	98mm (3.9 inches)
