Honda VFR800 ABS User Manual

Refer to the Safety Precautions on page .
Raise the front wheel off the ground by
placing a support block under the engine.
Cover both sides of the front wheel with a
protective tape ( ) or equivalent.
Remove the socket bolt A ( ) and socket
bolt B ( ).
3.
(2)
(3)
1.
2.
87 3
1
2
(1)
(1) Protective tape (2) Socket bolt A (3) Socket bolt B
WHEEL REMOVAL
Front Wheel Removal
116
08/08/06 10:12:39 32MCW660_126
Classic Cycles Technical Resources

Honda VFR800 ABS Specifications

General

Displacement	782 cc
Bore x Stroke	72 mm x 48 mm
Compression Ratio	11.8:1
Fuel System	PGM-FI electronic fuel injection
Transmission	6-speed
Final Drive	Chain
Wheelbase	57.4 inches
Engine Type	Liquid-cooled 4-stroke 16-valve DOHC 90° V-4
Rear Brakes	Single 256mm disc with 2-piston caliper and ABS
Front Tire	120/70ZR-17
Rear Tire	180/55ZR-17
