Honda VFR800 ABS User Manual

The front of the fuel tank can be tilted up
for maintenance.
The fuel tank does not require draining.
To Raise:
Place the motorcycle on its center stand
on a firm, level surface with the
transmission in neutral and the ignition
switch OFF. Check that the fuel fill cap is
closed.
Remove the seat (page ).
Remove the bolts ( ) with washers ( )
and the collars ( ).
1.
2.
3.
(1)
(2)
(3)
58
3
12
(1) Bolts
(2) Washers
(3) Collars
FUEL TANK MAINTENANCE
POSITION
67
08/08/06 10:06:06 32MCW660_077
www.ClassicCycles.org

Honda VFR800 ABS Specifications

General

Displacement	782 cc
Bore x Stroke	72 mm x 48 mm
Compression Ratio	11.8:1
Fuel System	PGM-FI electronic fuel injection
Transmission	6-speed
Final Drive	Chain
Wheelbase	57.4 inches
Engine Type	Liquid-cooled 4-stroke 16-valve DOHC 90° V-4
Rear Brakes	Single 256mm disc with 2-piston caliper and ABS
Front Tire	120/70ZR-17
Rear Tire	180/55ZR-17
