Honda VFR800 ABS User Manual

Push the dimmer switch to (HI) to
select high beam or to (LO) to select
low beam.
When this switch is pressed, the headlight
flashes on to signal approaching cars or
when passing.
Move to (L) to signal a left turn,
(R) to signal a right turn. Press to turn
signal off.
Press the button to sound the horn.
(2)
(1)
(4) (3)
(1) Headlight dimmer switch
(2) Passing light control switch
(3) Turn signal switch
(4) Horn button
LEFT HANDLEBAR CONTROLS
Headlight Dimmer Switch ( )
Passing Light Control Switch ( )
Turn Signal Switch ( )
Horn Button ( )
2
3
1
4
56
08/08/06 10:04:39 32MCW660_066
Classic Cycles Technical Resources

Honda VFR800 ABS Specifications

General

Displacement	782 cc
Bore x Stroke	72 mm x 48 mm
Compression Ratio	11.8:1
Fuel System	PGM-FI electronic fuel injection
Transmission	6-speed
Final Drive	Chain
Wheelbase	57.4 inches
Engine Type	Liquid-cooled 4-stroke 16-valve DOHC 90° V-4
Rear Brakes	Single 256mm disc with 2-piston caliper and ABS
Front Tire	120/70ZR-17
Rear Tire	180/55ZR-17
