18 Mounting and Connection Instructions - Door module RS485
6.1.7 DIP switch addresses
Set up the BUS address according to the following selection table.
A reset or a “power-on reset” must be carried out for any changes in the switch settings to be effective.
We recommend to set up the DIP switch before system commissioning.
Selection table 1: DIP switch S1 - S5 Address
1 2 3 4 5 Address
1 0 0 0 0 Address 1
0 1 0 0 0 Address 2
1 1 0 0 0 Address 3
0 0 1 0 0 Address 4
1 0 1 0 0 Address 5
0 1 1 0 0 Address 6
1 1 1 0 0 Address 7
0 0 0 1 0 Address 8
1 0 0 1 0 Address 9
0 1 0 1 0 Address 10
1 1 0 1 0 Address 11
0 0 1 1 0 Address 12
1 0 1 1 0 Address 13
0 1 1 1 0 Address 14
1 1 1 1 0 Address 15
0 0 0 0 1 Address 16
1 0 0 0 1 Address 17
0 1 0 0 1 Address 18
1 1 0 0 1 Address 19
0 0 1 0 1 Address 20
1 0 1 0 1 Address 21
0 1 1 0 1 Address 22
1 1 1 0 1 Address 23
0 0 0 1 1 Address 24
1 0 0 1 1 Address 25
0 1 0 1 1 Address 26
1 1 0 1 1 Address 27
0 0 1 1 1 Address 28
1 0 1 1 1 Address 29
0 1 1 1 1 Address 30
1 1 1 1 1 Address 31
0 0 0 0 0 Address 32
0 = OFF 1 = ON
DIP switch S6 - S8 don´t change factory setting “OFF”!
