6 - 35
Code 16K
Code 16K Message Length
Scan the bar codes belo
w to change the message length. Refer to
Message
Length
on page 6-2 for additi
onal information. Minimum and Maximum
lengths = 0-160. Minimum Default = 1, Maximum Default = 160.
Code 49
<Default All Code 49 Settings>
Code 49
On
* Off
Minimum Message Length
Maximum Message Length
* On
Off
124
126
