Honeywell HD5 Series User Manual

16
Installation
There are three installation options, and the installation process is slightly
different for each. Please see the following table for the steps for installing
your camera:
Ceiling or Wall
Mount (without
back box)
Ceiling or Wall
Mount (with back
box) (See note
on page 17)
Pendant Dome
Installing the
lens
see Installing the Lens on page 17
Installing the
mount
see Installing
without a Back Box
on page 19
see Installing with a
Back Box (ceiling or
wall mount) on page
22
see Installing a
Pendant Dome on
page 20
Making the
connections
see step 3 on
page 22
see Cable Options on page 15
Positioning
the camera
Adjusting the Field of View (FOV) on page 25
Adjusting the
lens (focus
and iris)
Focusing the Lens on page 26
