53
13.3 Spare parts drawings
The next pages show the following drawings:
• Figure 13-1 : general assembly, list of the main spare parts
• Figure 13-2: display unit assembly TS 10210, details
• Figure 13-3: battery holder assembly TS 10189, details
• Figure 13-4: electronic box assembly TS 10190, details
• Figure 13-5: storage tube SS1-Q1 TS 10186, details
• Figure 13-6: storage tube SS1-Q2 TS 10187, details
• Figure 13-7: storage tube SS2-Q2 with load TS 10188,
details
• Figure 13-8: tape cleaner assembly TS 10206, details
40300 Socket head cap screw M3x8
40303 Socket head cap screw M4x12
40306 Socket head cap screw M3x10
40316 Socket head cap screw M3x6
40319 Socket head cap screw M3x30
40326 Socket head cap screw M3x20
40327 Socket head cap screw M3x25
40555 Spacer M-M M3x6/M3x8
40611 Slotted at head mach. screw M5x16
40621 Flat head socket screw M5x12
40775 Cover cap S6
40776 Socket button head cap screw M4x12
40853 Socket set screw M3x3
40857 Socket set screw M4x6
40859 Socket set screw M4x4
40905 Circlip Ø1.9
40906 Crescent ring Ø17 Benzing
