Honeywell HPFF8CM User Manual

NAC Circuit Wiring Installation
HPFF8(E)/HPFF8CM(E) NAC Expander — P/N 53499:B4 10/1/2018 19
2.4 NAC Circuit Wiring
For wiring sizes, see Section 6.5, “NAC Circuit Loop Wiring Requirements”.
2.4.1 Four NACs Configured for Class B (Style Y)
Figure 2.10 shows four NACs configured for Class B (Style Y).
+
-
+
-
+
-
+
-
TB3
TB4
TB1
TB2
SW2
LEDs
REF+ REF– + IN – IN
+ OUT
– IN
+ OUT+ OUT
+ IN
– OUT
SIGNAL 1
SIGNAL 2
BATT+ BATT–
A+
N/O
N/C
COMM
N/O
N/C
COMM
AC FAIL
TROUBLE
J1
J2
1L1 1L2 2L1 2L2 3L1 3L2 4L1 4L2A–
NAC 3
Reference Resistor
F
F
8
1
2
N
A
C
C
l
a
s
s
B
.
w
m
f
Horn Strobe
Horn Strobe
Horn Strobe
ELR same as
Reference Resistor
Alarm Polarity Shown
• Trouble on NAC1 will illuminate
LED1 SIG1 TRBL.
• Trouble on NAC2 will illuminate
LED2 SIG2 TRBL.
• Trouble on NAC3 will illuminate
LED3 SIG3 TRBL.
• Trouble on NAC4 will illuminate
LED4 SIG4 TRBL.
NAC 4
NACs 1 - 3 are wired the same as NAC4 and
use the same ELR as the Reference Resistor.
NAC 1 NAC 2
Figure 2.10 Four NACs in Class B (Style Y)
NOTES:
1. Typical ELRs for new installations can be 3.9k or 4.7k ohm.
2. The same gauge wire must be used if two conductors are connected to the same terminal of any terminal block.
3. Do not complete a continuous circuit around the screw terminal. There must be two separate wires on either side of the screw at the
terminal block. “T-tapping” is absolutely NOT ALLOWED.

Honeywell HPFF8CM Specifications

General

Brand	Honeywell
Model	HPFF8CM
Category	Extender
Language	English
