Honeywell LYNX Touch L5200 Series Programming Guide

- 22 -
Zone Programming Worksheet
Zone
No.
Loop
No.
Device
Type
Response
Type Report Chime Supervision
Arm
Night
Transmitter
Serial Number
Zone
Descriptor
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
180 N/A Temperature Monitor Yes Disabled High Temp N/A N/A
181 N/A Temperature
Monitor
Yes Disabled Low Temp N/A N/A
182 N/A Temperature
Monitor
Yes Disabled High Temp N/A N/A
183 N/A Temperature
Monitor
Yes Disabled Low Temp N/A N/A
184 N/A Temperature
Monitor
Yes Disabled High Temp N/A N/A
185 N/A Temperature
Monitor
Yes Disabled Low Temp N/A N/A
186 N/A Temperature
Monitor
Yes Disabled High Temp N/A N/A
187 N/A Temperature
Monitor
Yes Disabled Low Temp N/A N/A
95 N/A Fire Fire No Verif. Yes Disabled Panic Trigger N/A
96 N/A Medical Not Used Yes Disabled Panic Trigger N/A
99 N/A Police 24 Hour Silent Yes Disabled Panic Trigger N/A
Explanation of Zone Assignment Table Headings
Loop Number - Used with 5800 Devices. Record transmitter loop number. Entries are 1-4, depending on device being used.
Refer to the transmitter’s instructions or the figure provided for appropriate loop numbers.
Device Type- Dependent upon the Zone Number being programmed.
Door Smoke Detector Flood Fire
Window Heat Sensor Environmental Garage Door
Motion Sensor Carbon Mono. Det. Medical Other
Glass Break Temperature Police
Response Type - Dependent upon the Device Type that has been selected.
Entry Exit 1 24 Hour Audible Trouble Resident Monitor
Entry Exit 2 24 Hour Auxiliary Arm Stay Resident Response
Perimeter Fire No Verification Arm Away General Monitor
Interior Follower Interior with Delay Disarm General Response
Day/Night Monitor No Response Fire With Verification
24 Hour Silent Carbon Monoxide Silent Burglary Garage
Garage Monitor
Supervision - Dependent upon the Zone Number being programmed.
Hardwire Zone
(Zone 1)
Wireless Zone
(Zone 2-64 L5200CN)
(Zone 2-80 L7000CN)
Key
(Zone 140-155 L5200CN)
(Zone 140-163 L7000CN)
Temperature
(Zone 180-185 L5200CN)
(Zone 180-187 L7000CN)
End of Line (Resistor) Supervised Button High Temp
Normal-Closed Unsupervised Low Temp
Normal-Open
