Screen Display Function & Programming Options
- 7 -
IP Fault Time (min)
00
IP Fault Time (min) (displayed if IP or WiFi is selected as Communications Path)
Enter 2-digits
00-99
Use DHCP
Yes
Use DHCP
.
Yes
No
Note: If No is selected the following options will be active
NIC IP Address
255.255.255.255
NIC IP Address (Appears only if “no” was selected in the “Use DHCP Field”)
Enter 4 part address
Subnet Mask
255.255.255.255
Subnet Mask (Appears only if “no” was selected in the “Use DHCP Field”)
Enter 4 part address
Gateway IP Address
255.255.255.255
Gateway IP Address (Appears only if “no” was selected in the “Use DHCP Field”)
Enter 4 part address
DNS Server IP Address
255.255.255.255
DNS Server Address (Appears only if “no” was selected in the “Use DHCP Field”)
Enter 4 part address
GSM Rollover
No
GSM Rollover (Appears only if “WiFi and GSM” was selected in the “Communications Path”
field)
Yes
No
GSM 24 Hour Test
No
GSM 24 Hour Test (Appears only if “WiFi and GSM” was selected in the “Communications
Path” field)
Yes
No
Program Zones
Zones
Select from the following zone options:
1. New
2. Front Door
3. Back Door
4. Window
5. Motion Sensor
6. New
7. – 45. New
46. – 48. New (Main)* Garage
Zones 46 to 48 are reserved for Garage Door Zones (L5200)
45. – 48. New (Main)* Garage
Zones 45 to 48 are reserved for Garage Door Zones (L7000)
49. – 64. New
Zones 48 to 64 (L5200)
49. – 80. New
Zones 49 to 80 (L7000)
140. – 147. 4 Button
Zones 140 to 147 (L5200 and L7000)
148. – 155. New (Button Zones)
Zones 148 to 155 (L5200 Only)
180. – 185. Temperature
Z-Wave Thermostat zones (L5200)
180. – 187. Temperature
Z-Wave Thermostat zones (L7000)
95. Fire
96. Medical
99. Police
Select a zone and then select “Edit” or “Add New” to program the next available zone.
Program the following options:(dependent upon Zone Type):
Serial Number Loop Number
Zone Description 1 Zone Description 2
Device Type Response Type
Report Chime Supervision
To Next Page
