Honeywell LYNX Touch L5200 Series Programming Guide

Screen Display Function & Programming Options
- 8 -
Serial Number
Serial Number
When “Serial Number” has been selected “Enter Serial Number or Activate” is displayed.
The transmitter serial number and loop number can be enrolled via RF transmission OR
manually.
Enroll via RF Learning To enroll the device using RF Learning mode three transmissions
(open/close) of the device will be required. The initial transmission activates the RF
Learning mode and the system will emit a single beep. A second transmission enrolls the
serial number and the system beeps two times and displays “Activate Sensor Again To
Confirm”. A third transmission will confirm the serial number. The system beeps two times
and returns to the Zone programming Screen.
Enroll Manually
Enter the 7-digit serial number printed on the transmitter using the displayed keypad and
select “Done”. The system beeps one time and returns to the Zone programming Screen.
Loop Number
1
Loop Number
1, 2, 3 or 4
Zone Description 1
Zone Description 2
Zone Description 1
The system announces the Zone Description. If desired, enter a zone descriptor.
Zone Description 2
The system announces the Zone Description. If desired, enter a zone descriptor.
Device Type
Device Type
Choose from the following options (dependant upon the Device Type):
New Door
Window Motion Sensor
Glass Break Smoke Detector
Heat Sensor Carbon Mono. Det.
Temperature Flood
Environmental Medical
Fire Police
Garage Door Other
Response Type
Not Used
Response Type Choose from the following options (dependant upon the Zone):
Not Used Arm Stay Fire No Verification
Entry Exit 1 Disarm Monitor
Entry Exit 2 Silent Burglary Garage
Interior Follower Resident Response Arm Away
24 Hour Silent General Response No Response
24 Hour Auxiliary Perimeter Resident Monitor
Interior With Delay Day/Night General Monitor
Carbon Monoxide 24 Hour Audible Fire With Verification
Garage Monitor Trouble
Report
Yes
Report
Yes
No
Chime
Disabled
Chime
Disabled Ascend Doorbell 1
Standard Ascend Long Doorbell 2
Melody Alert 1 Evolve
Melody Long Alert 2
Supervision
Supervised
Supervision
Hardwire Zone
Normal Open
Normal Closed
End of Line
RF Zone
Supervised
Unsupervised
Temperature
High Temp
Low Temp
Arm Night
No
Arm Night (Only available if “Motion Sensor” is selected in the “Response Type” field.
Yes
No
