– 75 –
SYSTEM FUNCTIONS
Testing the System (to be conducted weekly)
WiFi ConfigDate Time
Ready To Arm
Events
Back
Reminders
KeypadUsers
5100-100-006-V0
Slide Show
Test
3. Select the “Test” icon. The system displays
the Test screen.
Ready To Arm
Back
5100-100-087-V0
Prod. Id. : DE Sw.
Rev.: 05.00
CRC Number: 0X****
Walk Test Dialer Test Reboot
4. Select the “Walk Test”, “Dialer Test” or
“Reboot” icon. If Walk Test is selected
proceed to Step 5. If Dialer Test is selected
proceed to Step 6. If Reboot is selected
proceed to Step 7.
5. “Walk Test…” is displayed on the system
status bar and the control sounds a single
beep every 30 seconds. Fault each zone as
described below.
6. If the dialer test is unsuccessful the system
will display a Reporter Failure message.
Contact your security service provider.
7. The system will reboot itself.
8. After the reboot sequence is completed,
conduct a Walk Test to verify that all
transmitters are operational in the system
.
Walk Test
FAULT ZONES. Open each protected door and window in turn and listen for three beeps
from the control, followed by the zone’s Voice Descriptor, if it is programmed. Identification
of each faulted protection point should appear on the display. The display will clear when the
door or window is closed.
Walk in front of any interior motion detectors (if used) and listen for three beeps and/or voice
descriptors, if programmed. The identification of the detector should appear on the display
when it is activated, and its voice descriptor will be announced (if programmed). The display
will clear when no motion is detected. Note that if wireless motion detectors are used, in
order to conserve battery life, there is a 3-minute delay between activations.
To test all smoke detectors, follow the manufacturer's instructions. The identification of each
detector should appear on the display when each is activated.
