Operating Instructions
MS-5UD/MS-10UD Series PN 52626:B 8/01/2008 113
4.7 Process Monitor Operation
Process Monitor operation will initiate the following events:
• The piezo sounder pulses ¼ second On and ¼ second Off
• The LCD displays a process monitor message along with the device name, type, adjective/
noun, associated zones and time/date
• Communicate the process monitor condition to the Central Station
• Relays programmed for process monitoring will be activated
• The alarm relay is not
activated
• Silenced alarms are not
resounded
• Timers are not started
• Store event in history buffer
Note that, like supervisories, process monitor signals latch, except when programmed for process
monitor autoresettable.
4.8 Hazard/Tornado Condition Operation
Hazard/Tornado Condition operation will initiate the following events:
• The piezo sounder pulses ½ second On, ½ second Off
• The LCD displays a hazard message along with the device name, type, adjective/noun,
associated zones and time/date
• Communicate the hazard condition to the Central Station
• Relays programmed for hazard will be activated
• The alarm relay is not
activated
• Silenced alarms are not
resounded
• Timers are not started
• Store event in history buffer
• Supervisory LED flashes ½ second On, ½ second Off
Hazard conditions latch.
4.9 Medical Alert Condition Operation
Medical Alert Condition operation will initiate the following events:
• The piezo sounder ½ second On, ½ second Off
• The LCD displays a medical alert message along with the device name, type, adjective/noun,
associated zones and time/date
• Communicate the medical alert condition to the Central Station
• Relays programmed for medical alert will be activated
• The alarm relay is not
activated
• Silenced alarms are not
resounded
• Timers are not started
• Store event in history buffer
• Supervisory LED flashes ½ second On, ½ second Off
Medical alert conditions latch.
