Installation
MS-5UD/MS-10UD Series PN 52626:B 8/01/2008 51
2.8.8.4 ANN-LED Connection to FACP
Figure 2.26 illustrates the ANN-LED board wiring connections to the FACP.
Figure 2.26 ANN-LED Connection to FACP
FACP
ANN-LED
ANN-BUS
+24 VDC
-24 VDC
