Installation
MS-5UD/MS-10UD Series PN 52626:B 8/01/2008 53
2.8.9.4 ANN-RLY Connection to FACP
Figure 2.28 illustrates the ANN-RLY board wiring connections to the FACP.
Figure 2.28 ANN-RLY Connection to FACP
FACP
ANN-RLY
ANN-BUS
+24 VDC
-24 VDC
