4.19.7 History
Pressing 1 while viewing Read Status Screen #3 will display the following screens:
The operator can view all events which have been stored in the history file, only alarms or other
events, such as troubles or supervisories, by pressing the corresponding number key.
4.19.8 Print
To print program data or control panel status, press 2 while viewing Read Status Screen #3. The
following screens will be displayed:
Pressing 1 while viewing Print Screen #1 allows the user to print the History file which will detail
all of the system activities since the file was last cleared from memory.
Pressing 2 while viewing Print Screen #1 allows the user to print the Walktest log which will detail
all of the system activations during walktest since the log was last cleared. Refer to "Walktest" on
page 102 for additional information on the display.
Pressing 3 while viewing Print Screen #1 will exit the Print operation.
Pressing 1 while viewing Print Screen #2 allows the user to view the printer settings.
READ STATUS
1=HISTORY
2=PRINTER
3=ANN-BUS
Read Status Screen #3
HISTORY
1=VIEW ALL
2=VIEW ALARMS
3=VIEW OTHER EVENTS
PRINT
1=HISTORY
2=WALKTEST LOG
3=EXIT PRINTING
PRINT
1=PRINTER OPTIONS
Print Screen #1
Print Screen #2
To Next Page
