26 UDACT-2 — Instruction Manual P/N 54089:B3 10/29/2019
Programming Secondary Number Event Codes
Default: Press to return the Setting fields to default values.
3.4 Secondary Number Event Codes
This screen displays the default Event Code assignments for the protocol selected for the secondary telephone line. The Event Codes are
user-programmable
Description
: This display-only field gives a text description of the Event Code.
Setting
: This field may be modified to accommodate the user. The field may be changed to an alpha code, numeric code, or alpha-
numeric code. SIA and “4+2” accommodate two digits, Ademco Contact ID accomodates three.
Copy Primary
: When the primary and secondary reporting formats are the same, this button will activate. Press to copy the Setting val-
ues entered at the Primary Number Event Codes tab.
Default: Press to return the Setting fields to default values.
3.5 Zone and Point Assignments
Zone and point assignments are displayed at this screen. The function default is to Fire Alarm.
ACS Point
: Automatically filled with ACS point numbers generated from the ACS addresses selected for monitoring in the General Set-
tings screens (see page 23).
Source:
This field appears when Zone reporting is selected in the General Settings screen (see page 23). It displays the zone source.
Figure 3.4 Secondary Number Event Codes Tab
Figure 3.5 Zone and Point Assignments Tab
