UDACT-2 — Instruction Manual P/N 54089:B3 10/29/2019 31
SIA Reporting Formats
A typical printout of alarm and trouble reports in the Ademco Contact ID Reporting Structure follows:
5.3 SIA
The SIA reporting format is as follows:
TT AAAA
• TT = Event code.
• AAAA = Zone or Device address.
Time Date
Rcvr/
Line ID
SSSS QXYX GG CCCC Description
11:28 10/14 11 2456 E110 00 C000 General Alarm
11:28 10/14 11 2456 E111 00 C046 Alarm SD46
11:28 10/14 11 2456 E300 00 C000 General Trouble
11:28 10/14 11 2456 E380 00 C046 Trouble SD46
11:28 10/14 11 2456 R110 00 C000 General Alarm Restore
11:28 10/14 11 2456 R111 00 C046 Alarm SD46 Restore
11:28 10/14 11 2456 R300 00 C000 General Trouble Restore
11:28 10/14 11 2456 R380 00 C046 Trouble SD46 Restore
NOTE:
18, which is used in the reporting structure to identify the transmission as Contact ID, is not printed out in the alarm and trouble
report.
In the sample report, SD46 refers to smoke detector at address 46 or in zone 46.
Q, which is the Event Qualifier for the reporting structure, is printed out in the report as an E for New Event or R for New
Restore.
CCCC, the first C is not transmitted by the UDACT-2 but is printed by the Central Station Receiver printer output.
Code Description
Event
Code
Code Description
Event
Code
General alarm code FA System 24 hour test w/ active event RY
Zone/point alarm code FA Manual test RX
General supervisory FS Security alarm restore BH
Zone/point supervisory FS Zone/point defined as fire alarm FA
General fault FT Disable zone/point report 00
AC fault AT Zone/point defined as supervisory FS
Zone/point fault FT Zone/point defined as pull station FA
Low battery fault YT Zone/point defined as heat detector FA
Telco primary line fault LT Zone/point defined as water flow SA
Telco secondary line fault LT Zone/point defined as duct detector FA
NAC fault YA Zone/point defined as pre-alarm FA
Comm. trouble primary # YC Zone/point defined as smoke FA
Comm. trouble secondary # YC Zone/point defined as burglary BA
485 comm. trouble YC Zone/point defined as non-burglary UA
System off normal FT Zone/point defined as high temperature KA
Reserved 00 Zone/point defined as low temperature ZA
Reserved 00 Zone/point defined as water pressure SS
Reserved 00 Zone/point defined as water level SS
Reserved 00 Zone/point defined as pump failure SS
Security alarm BA Zone/point defined as photo/co detector GA
General alarm restore FH Zone/point defined as fire alarm restore FH
Zone/point alarm restore FH Disable zone/point report restore 00
General supervisory restore FV Zone/point defined as supervisory restore FV
Zone/point supervisory restore FV Zone/point defined as pull station restore FH
Table 5.3 SIA Event Codes (1 of 2)
