XNX Universal Transmitter
Warnings/Faults
125
Notes
Note 3:
Subtypes Decimal Description
Fault 2 Event
Bits
1
CRC error in safety critical RAM block
2
Error reloading safety critical RAM block from EEPROM
4
Error loading data from Personality board
8
Excel signal level has been below the low signal level
threshold for at least 24 hours
16
Excel beam blocked
32
Personality board error code > 0
64
Option board error code > 0
128
IR mA input > 1 mA and < 3.4 mA
256
IR mA input < 1.0 mA
512
IR forced 10 mA not within +/-1 mA
1024
gains from PGA don't match local copy
2048
error reading or writing EEPROM
4096
ECC reex failure
8192
RAM test failure
16384
Program memory CRC failure
32768
Op code test failure
Fault 3 Event
Bits
1 Interrupt integrity test failure
Note 4:
Optima and Excel fault and warning codes are displayed in the Event History data eld.
