4 Removal and replacement procedures
preliminary requirements
Use this information to properly prepare to disassemble and reassemble the computer.
Tools required
You need the following tools to complete the removal and replacement procedures:
● Tweezers
● Nonconductive, nonmarking pry tool
● Magnetic Phillips P1 screwdriver
Service considerations
The following sections include some of the considerations that you must keep in mind during disassembly
and as
sembly procedures.
NOTE: As you remove each subassembly from the computer, place the subassembly (and all accompanying
scr
ews) away from the work area to prevent damage.
Plastic parts
Using excessive force during disassembly and reassembly can damage plastic parts.
Cables and connectors
Handle cables with extreme care to avoid damage.
IMPORTANT: When servicing the computer, be sure that cables are placed in their proper locations during
the r
eassembly process. Improper cable placement can damage the computer.
Apply only the tension required to unseat or seat the cables during removal and insertion. Handle cables by
the c
onnector whenever possible. In all cases, avoid bending, twisting, or tearing cables. Be sure that cables
are routed so that they cannot be caught or snagged as you remove or replace parts. Handle ex cables with
extreme care; these cables tear easily.
Drive handling
Note the following guidelines when handling drives.
24 Chapter 4 Removal and replacement procedures preliminary requirements
