Rear panel components
Item Component Item Component
1 Line-In audio connector 6 USB 2.0 ports (2)
2 Line-in audio connector (blue) 7 USB 3.x SuperSpeed ports (2)
3 Serial port 8 USB 2.0 Type-C ports (2)
4 HDMI connector 9 Graphics card slots
5 VGA monitor connector 10 RJ-45 network connector
11 Power cord connector
NOTE: An optional second serial port and an optional parallel port are available from HP.
When a device is plugged into the blue Line-In audio connector, a dialog box will pop up asking if you want to use the
connector for a line-in device or a microphone. You can recongure the connector at any time by double-clicking the
Audio Manager icon in the Windows taskbar.
When a graphics card is installed in one of the system board slots, the video connectors on the graphics card and/or the
integrated graphics on the system board may be used. The specic graphics card installed and software conguration
will determine the behavior.
The system board graphics can be disabled by changing settings in Computer Setup.
Serial number location
Each computer has a unique serial number and a product ID number that are located on the exterior of the
computer. Keep these numbers available for use when contacting customer service for assistance.
Rear panel components 3
