Installing a slim optical drive
1. Prepare the computer for disassembly (Preparation for disassembly on page 15).
2. Remove the access panel (Access panel on page 16).
3. If you are installing a slim optical drive in a bay covered by a bezel blank, remove the front bezel and then
remove the bezel blank. See Front bezel on page 17 for more information.
4. Follow the instructions for removing the optical drive if one was installed. Refer to Removing a slim optical
drive on page 28.
5. Align the small pin on the release latch with the small hole on the side of the drive and press the latch
rmly onto the drive.
30 Chapter 4 Removal and replacement procedures
