Specifications 6–2

12.1-inch, WXGA display specifications

Hard drive specifications

Metric U.S.

Dimensions

Height 16.9 cm 6.7 in

Width 26.2 cm 10.3 in

Diagonal 30.8 cm 12.1 in

Number of colors Up to 16.8 million

Contrast ratio 250:1 (typical)

Brightness 180 nits (typical)

Pixel resolution

Pitch 0.279 × 0.279 mm

Format 1280 × 800

Configuration RGB vertical stripe

Backlight Edge lit

Character display 80 × 25

Total power consumption 4.0 W

Viewing angle +/-40° horizontal, +120/-40° vertical (typical)

320-GB* 250-GB* 160-GB* 120-GB*

Dimensions

Height 9.5 mm 9.5 mm 9.5 mm 9.5 mm

Width 70 mm 70 mm 70 mm 70 mm

Weight 101 g 101 g 101 g 101 g

Interface type SATA S ATA S ATA SATA

Transfer rate 100 MB/sec 100 MB/sec 100 MB/sec 100 MB/sec

Security ATA security ATA security ATA security ATA security

Seek times (typical read, including setting)

Single track 3 ms 3 ms 3 ms 3 ms

Average 13 ms 13 ms 13 ms 13 ms

Maximum 24 ms 24 ms 24 ms 24 ms

Logical blocks 625,142,448 488,397,168 312,581,808 234,441,648

Disc rotational speed 5400 rpm 5400 rpm 5400 rpm 5400 rpm

Operating temperature 5°C to 55°C (41°F to 131°F)

*1 GB = 1 billion bytes when referring to hard drive storage capacity. Actual accessible capacity is less. Actual drive

specifications may differ slightly.

✎

Certain restrictions and exclusions apply. Contact technical support for details.
