Phillips PM2.0×5.0 captive screw
Color Quantity Length Thread Head diameter
Black 8 5.0 mm 2.0 mm 4.5 mm
Where used:
(1) One screw that secures the Bluetooth module compartment cover to the computer (screw is
captured on the cover by a C-clip)
(2) Two screws that secure the memory module/WLAN module compartment cover to the computer
(screws are captured on the cover by C-clips)
(3) Two screws that secure the hard drive cover to the computer (screws are captured on the cover
by C-clips)
(4) One screw that secures the WWAN module compartment cover to the computer (screw is
captured on the cover by a C-clip)
98 Chapter 7 Screw listing
