Torx T8M2.5×7.0 screw
Color
Quantity
Length
Thread
Head
diameter
Black
20
7
.0 mm
2.5 mm
5.0 mm
Where used
:
(1)
One screw that secures the op
tical drive to the computer
(2)
Six screws that secure the keyboard to the computer
Where used
:
2 screws that secure the disp
lay assembly to the computer
Torx T8M2.5×7.0 screw
103
112
114
Table of Contents
Default Chapter
7
Table of Contents
7
1 Product Description
11
2 External Component Identification
15
Display Components
15
Top Components
16
Buttons and Fingerprint Reader
16
Keys
17
Lights
18
Pointing Devices
20
Front Components
21
Left-Side Components
22
Rear Components
23
Right-Side Components
24
Bottom Components
26
3 Illustrated Parts Catalog
28
Serial Number Location
28
Computer Major Components
29
Plastics Kit
35
Cable Kit
36
Mass Storage Devices
37
Miscellaneous Parts
37
Sequential Part Number Listing
39
4 Removal and Replacement Procedures
44
Preliminary Replacement Requirements
44
Tools Required
44
Service Considerations
44
Plastic Parts
44
Cables and Connectors
45
Drive Handling
45
Grounding Guidelines
46
Electrostatic Discharge Damage
46
Packaging and Transporting Guidelines
47
Workstation Guidelines
47
Equipment Guidelines
48
Unknown User Password
49
Component Replacement Procedures
50
Computer Feet
50
Serial Number
50
Battery
51
Sim
52
Bluetooth Module
53
Memory Module
55
RTC Battery
57
WLAN Module
58
Hard Drive
62
WWAN Module
64
Optical Drive
66
Switch Cover
67
Keyboard
69
Display Assembly
72
Top Cover
77
System Board
80
Speaker Assembly
83
Fan/Heat Sink Assembly
84
PC Card Assembly
86
Modem Module
88
5 Computer Setup
90
Starting Computer Setup
90
Using Computer Setup
91
Navigating and Selecting in Computer Setup
91
Restoring Factory Settings in Computer Setup
91
Computer Setup Menus
92
File Menu
92
Security Menu
93
Diagnostics Menu
93
System Configuration Menu
94
6 Specifications
96
Computer Specifications
96
12.1-Inch, WXGA Display Specifications
97
Hard Drive Specifications
98
DVD±RW and CD-RW Double-Layer Combo Drive Specifications
99
DVD/CD-RW Combo Drive Specifications
100
DVD-ROM Drive
101
System DMA Specifications
102
System Interrupt Specifications
103
System I/O Address Specifications
104
System Memory Map Specifications
106
7 Screw Listing
107
Phillips PM2.0×5.0 Captive Screw
108
Phillips PM2.0×5.0 Screw
110
Phillips PM2.5×4.0 Screw
111
Torx T8M2.5×7.0 Screw
113
Torx T8M2.5×4.0 Screw
116
Phillips PM2.0×3.0 Screw
118
Phillips PM1.5×3.0 Screw
119
Torx T6M2.0×5.0 Screw
120
Phillips PM2.0×4.0 Screw
121
Phillips PM2.0×2.0 Broad-Head Screw
122
Phillips PM2.0×10.0 Screw
123
8 Backup and Recovery
124
Backup and Recovery Using Windows Vista
124
Creating Recovery Discs
124
Backing up Your Information
124
Backing up Specific Files or Folders
125
Backup Suggestions
125
When to Back up
125
Backing up the Entire Hard Drive
126
Creating Recovery Points
127
Scheduling Backups
127
Performing a Recovery
127
Performing a Recovery from the Hard Drive
128
Performing a Recovery from the Recovery Discs
128
Initiating a Recovery from the Hard Drive Recovery Partition
129
Initiating a Recovery in Windows
129
Backup and Recovery Using Windows XP
130
Creating Recovery Discs
130
Backing up Your Information
130
Backing up Specific Files or Folders
131
Backup Suggestions
131
When to Back up
131
Backing up the Entire Hard Drive
132
Creating Recovery Points
133
Scheduling Backups
133
Performing a Recovery
133
Performing a Recovery from the Hard Drive
134
Performing a Recovery from the Recovery Discs
134
Initiating a Recovery from the Hard Drive Recovery Partition
135
Initiating a Recovery in Windows
135
9 Connector Pin Assignments
136
Audio-Out (Headphone)
136
Audio-In (Microphone)
136
External Monitor
137
Modem)
138
Network)
138
Universal Serial Bus
139
10 Power Cord Set Requirements
140
Requirements for All Countries and Regions
140
Requirements for Specific Countries and Regions 131
141
11 Recycling
142
Battery
142
Display
142
Index
148
