HP Compaq 6530s User Manual

7 Screw listing
This chapter provides specification and reference information for the screws and screw locks used in
the computer. All screws listed in this section are available in the Screw Kit, spare part numbers
493176-001 (for use only with HP Compaq 6535s Notebook PC models) and 491655-001 (for use only
with HP Compaq 6530s and 6531s Notebook PC models).
Slotted Torx ST8M2.5×7.0 screw
Color Quantity Length Thread Head diameter
Black 18 7.0 mm 2.5 mm 5.0 mm
Where used:
(1) One screw that secures the optical drive to the computer
(2) Seven screws that secure the top cover to the computer
Slotted Torx ST8M2.5×7.0 screw 111
