Phillips PM2.5×6.0 captive screw
Color Quantity Length Thread Head diameter
Black 4 6.0 mm 2.5 mm 5.0 mm
Where used:
(1) Two captive screws that secure the hard drive bay cover to the computer (screws are secured by C-
clips)
(2) One captive screw that secures the WLAN module compartment cover to the computer (screw is
secured by a C-clip)
(3) One captive screw that secures the memory module compartment cover to the computer (screw is
secured by a C-clip)
Phillips PM2.5×6.0 captive screw 115
