2–10 www.hp.com Hardware Reference Guide
Hardware Upgrades
Installing DDR-SDRAM DIMMs
Ä
CAUTION: The memory module sockets have gold metal contacts. When
upgrading the memory, it is important to use memory modules with gold
metal contacts to prevent corrosion and/or oxidation resulting from having
incompatible metals in contact with each other.
Ä
CAUTION: Static electricity can damage the electronic components of
the computer or optional cards. Before beginning these procedures,
ensure that you are discharged of static electricity by briefly touching a
grounded metal object. For more informations, refer to Appendix F,
“Electrostatic Discharge”.
Ä
CAUTION: When handling a memory module, be careful not to touch
any of the contacts. Doing so may damage the module.
1. If you have locked the Smart Cover Lock, see the “Smart Cover
Lock” section or use Computer Setup to unlock it.
2. Turn off the computer properly through the operating system and
turn off any external devices. Disconnect the power cord from the
power outlet.
3. Remove the access panel and locate the memory module sockets.
Å
WARNING: To reduce risk of personal injury from hot surfaces, allow
the internal system components to cool before touching.
4. Open both latches of the memory module socket 1, and insert the
memory module into the socket 2.
✎
If you have one preinstalled DIMM in socket XMM1 and are adding a
second DIMM, it is recommended that you install an identical DIMM
into the XMM3 socket. If you are populating all four DIMM sockets,
use identical DIMMs in each socket. Otherwise, the system will not
operate in dual channel mode.
