1–8 Getting Started
Hardware Setup
Network Card
Your notebook has an RJ-45 (network) jack, an internal network
interface card (NIC), and preinstalled network drivers.
Connecting a Network Cable
A network cable has an 8-pin RJ-45 network connector at each
end and may contain noise suppression circuitry, which prevents
interference with TV and radio reception.
To connect the network cable:
1. Confirm that the existing LAN supports Ethernet
10BASE-T/100BASE-TX/1000BASE-T connections.
2. If the network cable contains noise suppression circuitry 1,
plug the circuitry end of the network cable 2 into the RJ-45
jack on the notebook.
3. Plug the other end of the cable 3 into an RJ-45 wall jack.
