HP Elite Dragonfly G2 User Manual

1. Type support in the taskbar search box, and then select the HP Support Assistant app.
– or –
Select the question mark icon in the taskbar.
2. Select Updates, and then select Check for updates and messages.
3. Follow the on-screen instructions.
4. At the download area, follow these steps:
a. Identify the most recent BIOS update and compare it to the BIOS version currently installed on your
computer. Make a note of the date, name, or other identier. You might need this information to
locate the update later, after it has been downloaded to your hard drive.
b. Follow the on-screen instructions to download your selection to the hard drive.
Make a note of the path to the location on your hard drive where the BIOS update is downloaded.
You will need to access this path when you are ready to install the update.
NOTE: If you connect your computer to a network, consult the network administrator before installing
any software updates, especially system BIOS updates.
Installing a BIOS update
BIOS installation procedures vary. Follow any instructions that are displayed on the screen after the download
is complete. If no instructions are displayed, follow these steps.
1. Type file in the taskbar search box, and then select File Explorer.
2. Select your hard drive designation. The hard drive designation is typically Local Disk (C:).
3. Using the hard drive path you recorded earlier, open the folder that contains the update.
4. Double-click the le that has an .exe extension (for example, lename.exe).
The BIOS installation begins.
5. Complete the installation by following the on-screen instructions.
NOTE: After a message on the screen reports a successful installation, you can delete the downloaded le
from your hard drive.
Changing the boot order using the f9 prompt
To dynamically choose a boot device for the current startup sequence, follow these steps.
1. Access the Boot Device Options menu:
● Turn on or restart the computer, and when the HP logo appears, press f9 to enter the Boot Device
Options menu.
2. Select a boot device, press enter, and then follow the on-screen instructions.
TPM BIOS settings (select products only)
TPM provides additional security for your computer. You can modify the TPM settings in Computer Setup
(BIOS).
58 Chapter 7 Computer Setup (BIOS), TPM, and HP Sure Start

HP Elite Dragonfly G2 Specifications

General

4G standard	LTE-TDD & LTE-FDD
Antenna type	2x2
Wi-Fi standards	Wi-Fi 6 (802.11ax)
Bluetooth version	5.0
WLAN controller model	Intel Wi-Fi 6 AX201
Mobile network connection	Yes
Mobile network generation	4G
WLAN controller manufacturer	Intel
Color gamut	72 %
Display surface	Gloss
RGB color space	NTSC
Display diagonal	13.3 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display brightness	400 cd/m²
Display diagonal (metric)	33.8 cm
Processor cache	8 MB
Processor cores	4
Processor model	i5-1135G7
Processor family	Intel® Core™ i5
Processor threads	8
Configurable TDP-up	28 W
Processor frequency	- GHz
Processor cache type	L3
Configurable TDP-down	12 W
Processor boost frequency	4.2 GHz
Configurable TDP-up frequency	2.4 GHz
Configurable TDP-down frequency	0.9 GHz
ECC	No
Memory slots	1x SO-DIMM
Internal memory	8 GB
Memory clock speed	4266 MHz
Memory form factor	On-board
Internal memory type	LPDDR4x-SDRAM
Battery weight	240 g
Battery capacity	56 Wh
Pointing device	Clickpad
Input device model	HP Premium Collaboration Keyboard
Keyboard special features	Spill-resistant
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express, NVMe
Storage media	SSD
Total storage capacity	256 GB
Number of SSDs installed	1
Color name	Galaxy blue
Form factor	Convertible (Folder)
Product type	Hybrid (2-in-1)
Product color	Blue
Country of origin	China
Market positioning	Premium
Original brand name	HP
Speakers manufacturer	Bang & Olufsen
Charging port type	USB Type-C
USB 2.0 ports quantity	0
Sustainability certificates	ENERGY STAR, TCO
HP segment	Business
Operating system installed	Windows 11 Pro
Discrete graphics card model	Not available
On-board graphics card model	Intel® UHD Graphics
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Front camera	-
Password protection type	BIOS, Power on, User
Trusted Platform Module (TPM) version	2.0
Package depth	449 mm
Package width	69 mm
Package height	305 mm

Weight and Dimensions

Depth	197.5 mm
Width	304.3 mm
Height	16.1 mm
Weight	990 g
