HP Elite Dragonfly G2 User Manual

Table 9-2 Display specications (continued)
Metric U.S.
Resolution 3840 × 2160 (UHD)
1920 × 1080 (FHD)
Surface treatment BrightView
Brightness 400 nits (FHD, UHD panels)
1000 nits (FHD privacy panels)
Viewing angle UWVA
Backlight WLED
Display panel interface eDP 1.4
Solid-state drive specications
This section provides specications for your solid-state drives.
Table 9-3 Solid-state drive specications
128 GB* 256 GB* 512 GB* 1 TB* 2 TB*
Dimensions
Height 1.0 mm 1.0 mm 1.0 mm 1.0 mm 1.0 mm
Length 50.8 mm 50.8 mm 50.8 mm 50.8 mm 50.8 mm
Width 28.9 mm 28.9 mm 28.9 mm 28.9 mm 28.9 mm
Weight < 10 g < 10 g < 10 g < 10 g < 10 g
Interface type PCIe PCIe PCIe PCIe PCIe
Ready time, maximum (to not busy) 1.0 ms 1.0 ms < 1.0 ms 1.0 ms 1.0 ms
Access times, logical 1.0 ms 0.1 ms 0.1 ms 0.1 ms 0.1 ms
Transfer rate
Sequential read up to 2150
MB/s
up to 2150
MB/s
up to 2150 MB/s up to 2150 MB/s up to 2150 MB/s
Random read Up to 300,000
IOPs
Up to 300,000
IOPs
Up to 300,000
IOPs
Up to 300,000
IOPs
Up to 300,000
IOPs
Sequential write up to 1550
MB/s
up to 1550
MB/s
up to 1550 MB/s up to 1550 MB/s up to 1550 MB/s
Random write Up to 100,000
IOPs
Up to 100,000
IOPs
Up to 100,000
IOPs
Up to 100,000
IOPs
Up to 100,000
IOPs
Total logical sectors 234,441,648 468,883,296 1,000,215,216 1,500,336,388 3,000,672,776
Operating temperature 0°C to 70°C (32°F to 158°F)
*1 GB = 1 billion bytes when referring to hard drive storage capacity. Actual accessible capacity is less. Actual drive specications can
dier slightly.
NOTE: Certain restrictions and exclusions apply. Contact support for details.
Solid-state drive specications 67

HP Elite Dragonfly G2 Specifications

General

4G standard	LTE-TDD & LTE-FDD
Antenna type	2x2
Wi-Fi standards	Wi-Fi 6 (802.11ax)
Bluetooth version	5.0
WLAN controller model	Intel Wi-Fi 6 AX201
Mobile network connection	Yes
Mobile network generation	4G
WLAN controller manufacturer	Intel
Color gamut	72 %
Display surface	Gloss
RGB color space	NTSC
Display diagonal	13.3 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display brightness	400 cd/m²
Display diagonal (metric)	33.8 cm
Processor cache	8 MB
Processor cores	4
Processor model	i5-1135G7
Processor family	Intel® Core™ i5
Processor threads	8
Configurable TDP-up	28 W
Processor frequency	- GHz
Processor cache type	L3
Configurable TDP-down	12 W
Processor boost frequency	4.2 GHz
Configurable TDP-up frequency	2.4 GHz
Configurable TDP-down frequency	0.9 GHz
ECC	No
Memory slots	1x SO-DIMM
Internal memory	8 GB
Memory clock speed	4266 MHz
Memory form factor	On-board
Internal memory type	LPDDR4x-SDRAM
Battery weight	240 g
Battery capacity	56 Wh
Pointing device	Clickpad
Input device model	HP Premium Collaboration Keyboard
Keyboard special features	Spill-resistant
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express, NVMe
Storage media	SSD
Total storage capacity	256 GB
Number of SSDs installed	1
Color name	Galaxy blue
Form factor	Convertible (Folder)
Product type	Hybrid (2-in-1)
Product color	Blue
Country of origin	China
Market positioning	Premium
Original brand name	HP
Speakers manufacturer	Bang & Olufsen
Charging port type	USB Type-C
USB 2.0 ports quantity	0
Sustainability certificates	ENERGY STAR, TCO
HP segment	Business
Operating system installed	Windows 11 Pro
Discrete graphics card model	Not available
On-board graphics card model	Intel® UHD Graphics
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Front camera	-
Password protection type	BIOS, Power on, User
Trusted Platform Module (TPM) version	2.0
Package depth	449 mm
Package width	69 mm
Package height	305 mm

Weight and Dimensions

Depth	197.5 mm
Width	304.3 mm
Height	16.1 mm
Weight	990 g
