2 System Specifications
This chapter describes the basic system configuration, physical specifications and requirements
for the server.
Dimensions and Weights
This section provides dimensions and weights of the server and server components. Table 2-1
gives the dimensions and weights for a fully configured server.
Table 2-1 Server Dimensions and Weights
PackagedStandalone
86.50 (219.70)29.55 (75.00)Height - Inches (centimeters)
40.00 (101.60)17.50 (44.50)Width - Inches (centimeters)
48.00 (122.00)30.00 (76.20)Depth - Inches (centimeters)
813.00
2
(368.77)368.00
1
(166.92)Weight - Pounds (kilograms)
1 This weight represents a fully configured server before it is installed in a rack.
2 The packaged weight represents a server installed in a 2-m rack. The packaged weight includes a fully configured
server in a 2-m rack with a rear door, rail slide kit, line cord anchor kit, interlock assembly, cable management arm,
120-lb ballast kit, and a 60-A PDU. The shipping box, pallet, and container, not included in the packaged weight in
Table 2-1, adds approximately 150.0-lb to the total system weight when shipped. The size and number of miscellaneous
pallets will be determined by the equipment ordered by the customer.
Table 2-2 provides component weights for calculating the weight of a server not fully configured.
Table 2-3 provides an example of how to calculate the weight. Table 2-4 is a blank worksheet for
calculating the weight of the server. To determine the overall weight, follow the example in
Table 2-3, and complete the worksheet in Table 2-4 for your system.
Table 2-2 Server Component Weights
Weight lb (kg)DescriptionQuantity
131.00 (59.42)Chassis1
20.0 (9.07)System backplane1
20.40 (9.25)PCI-X I/O backplane assembly1
5.00 (2.27) eachPCI-X power supply2
12.00 (5.44) eachBulk power supply6
1.00 (0.45)Mass storage backplane1
27.80 (12.61) eachCell board1 - 4
1.60 (0.73) eachHard disk drive1 - 4
2.20 (1.00) eachRemovable media disk drive1 - 2
Table 2-3 Example Weight Summary
Weight (kg)MultiplyQuantityComponent
107.20 lb
48.64 kg
27.8 lb
12.16 kg
4Cell board
1.36 lb
0.61 kg
0.34 lb
0.153 kg
4PCI card (varies - used sample
value)
Dimensions and Weights 33
