2. Cut and join them together (as necessary) to create a scale model floor plan of your computer
room.
3. Remove a copy of each applicable equipment footprint template (Figure A-2).
4. Cut out each template selected in step 3; then place it on the floor plan grid created in step
2.
5. Position pieces until you obtain the desired layout, then fasten the pieces to the grid. Mark
locations of computer room doors, air-conditioning floor vents, utility outlets, and so on.
NOTE: Attach a reduced copy of the completed floor plan to the site survey. HP installation
specialists use this floor plan during equipment installation.
Figure A-2 Server Cabinet Template
42 Templates
