Replacement procedure
CAUTION:
SICs and DSICs are not hot swappable. Make sure the router is powered off before replacing a SIC or
DSIC.
Replacing a SIC
1. Loosen the captive screws on the SIC.
2. Gently pull the SIC out along the slide rails.
3. Install a new SIC. For the installation procedure, see "Installing the router."
If you do not install a SIC, install a filler panel and tighten the screws.
Figure 26 Removing a SIC
Figure 27 Installing a filler panel
Replacing a DSIC
1. Loosen the captive screws on the DSIC.
2. Gently pull the DSIC out along the slide rails.
If you need to install a DSIC or SICs, see "Installing the router" for the installation procedure.
26
