HP MSR4080 Installation Guide

33
Figure 36 Rear view
(1) SIC slot 3 (2) SIC slot 2
(3) SIC slot 1 (4) Groundin
g
terminal
Technical specifications
Item MSR1002-4 MSR1003-8 MSR1003-8S
Console/AUX port 1 1 1
USB port 1 1 1
Gigabit Ethernet port 5 10 10
SFP port 1 N/A N/A
Asynchronous/synchr
onous serial interface
1 N/A N/A
Memory 1 GB DDR3 1 GB DDR3 1 GB DDR3
Flash 256 MB 256 MB 256 MB
SIC/DSIC slot 2 SIC slot (1 DSIC slot) 3 SIC slots (1 DSIC slot) 3 SIC slots (1 DSIC slot)
Dimensions (H × W ×
D)
44.2 × 360 × 300 mm
(1.74 × 14.17 ×
11.81 in)
44.2 × 360 × 300 mm (1.74
× 14.17 × 11.81 in)
44.2 × 360 × 300 mm
(1.74 × 14.17 × 11.81 in)
(excluding rubber feet
and mounting
brackets)
Rated voltage range:
90 VAC to 264 VAC
@ 50 Hz/60 Hz
Rated voltage range: 90
VAC to 264 VAC @ 50
Hz/60 Hz
Rated voltage range: 90
VAC to 264 VAC @ 50
Hz/60 Hz
AC power supply
Rated power for AC
power supply
30 W 30 W 30 W
Operating
temperature
0°C to 45°C (32°F to
113°F)
0°C to 45°C (32°F to
113°F)
0°C to 45°C (32°F to 113°F)
Relative humidity
5% to 90% 5% to 90% 5% to 90%
(noncondensing)
