Notebook Hardware Structure
The following guidelines apply to all subassembly level repairs
w Properly ground yourself and your work area to prevent damage from static discharge
w Always replace any conductive sponge material or thermal tape that becomes damaged during repairs.
w Use a #0 Phillips screwdriver to remove all screws
Field Replaceable Assemblies
Removing LCD Assy and Icon Assy (Hewlett-Packard Authorized Service Providers Only)
The LCD Assy and/or Icon Assy on the OmniBook 5500CS and CT are removed the same way as on the OmniBook 5000. Turn the unit over,
raise the feet, and withdraw the two Phillips screws (screw - display) from under the feet in the bottom back corners of the unit (see diagram
below which shows the OmniBook 5000).
18
