8. Lower the mylar protector from the assembly (4).
Reverse this procedure to reassemble and install the hard drive.
Keyboard
NOTE: For a detailed list of available keyboards, see Sequential part number listing on page 26.
Description Spare part number
Keyboard for use with models using Windows 7 683491-xxx
Keyboard for use with models using Windows 8 702237-xxx
Before removing the keyboard, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet,
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 37).
5. Remove the bottom door (see
Bottom door on page 38).
6. Remove the Optical drive (see
Optical drive on page 41).
Component replacement procedures 47

HP ProBook 4545s Specifications

General

Optical Drive	DVD+/-RW SuperMulti DL
Bluetooth	Bluetooth 4.0
Card Reader	SD/MMC
Graphics	AMD Radeon HD 7520G
Display	15.6-inch HD anti-glare LED-backlit (1366 x 768)
Operating System	Windows 8 Pro
Battery	6-cell Li-ion
Wireless	802.11b/g/n
Ports	HDMI, VGA, RJ-45, headphone/microphone combo jack
Webcam	720p HD
Processor	AMD A-Series
